Toyota Land Cruiser
2024-02 → present · chassis TJH250 · catalogue 781490 · United States
Supported model
Data version 2024-02
Armrest & Visor
25 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 74037 | Cover Sub-assy, Front Door Armrest, RH |
| 74038 | Cover Sub-assy, Front Door Armrest, LH |
| 74047A | Cover Sub-assy, Rear Door Armrest, RH |
| 74048A | Cover Sub-assy, Rear Door Armrest, LH |
| 74231 | Panel, Front Armrest Base, Upper RH |
| 74232 | Panel, Front Armrest Base, Upper LH |
| 74271A | Panel, Rear Door Armrest Base, Upper RH |
| 74272A | Panel, Rear Door Armrest Base, Upper LH |
| 74310 | Visor Assy, RH |
| 74320 | Visor Assy, LH |
| 74325 | Cover, Visor Bracket |
| 74348C | Holder, Visor, LH |
| 74610A | Grip Sub-assy, Assist |
| 74611B | Grip, Assist |
| 74612 | Cover, Assist Grip |
| 74612F | Cover, Assist Grip |
| 74617C | Plug, Assist Grip |
| 74617F | Plug, Assist Grip |
| 74617V | Plug, Assist Grip |
| 74617W | Plug, Assist Grip |
| 74620C | Grip Assy, Assist, Rear RH |
| 74630E | Grip Assy, Assist, Rear LH |
| 74680 | Grip Assy, Pillar Assist |
| 74680B | Grip Assy, Pillar Assist, RH |
| 74680C | Grip Assy, Pillar Assist, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
