Toyota Land Cruiser
2024-02 → present · chassis TJH250 · catalogue 781490 · United States
Supported model
Data version 2024-02
Moulding
66 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 60117 | Cover Sub-assy, Front Pillar, Upr RH |
| 60118 | Cover Sub-assy, Front Pillar, Upr LH |
| 61991B | Protector, Front Pillar Cover, RH |
| 61992 | Protector, Front Pillar Cover, LH |
| 62791G | Moulding, Quarter Window, Upper RH |
| 62792V | Moulding, Quarter Window, Upper LH |
| 67495C | Cover, Front Door Front Lower Frame, Upper RH |
| 67496C | Cover, Front Door Front Lower Frame, Upper LH |
| 75061 | Moulding Set, Outside |
| 75062 | Moulding Set, Outside, LH |
| 75073 | Moulding Sub-assy, Front Door, Outside Lower RH |
| 75074 | Moulding Sub-assy, Front Door, Outside Lower LH |
| 75075A | Clip(FOR REAR DOOR OUTSIDE MOULDING) |
| 75077 | Moulding Sub-assy, Rear Door Outside Lower RH |
| 75078 | Moulding Sub-assy, Rear Door Outside Lower LH |
| 75392A | Retainer, Outside Moulding, NO.1 |
| 75392H | Retainer, Outside Moulding |
| 75535F | Moulding, Windshield, Outside Lower RH |
| 75536B | Moulding, Windshield, Outside Lower LH |
| 75545B | Clip, Windshield Outside Moulding, NO.1 |
| 75547B | Clip, Windshield Outside Moulding, NO.3 |
| 75548A | Fastener, Windshield Outside Moulding, NO.1 |
| 75551 | Moulding, Roof Drip Side Finish, RH |
| 75552 | Moulding, Roof Drip Side Finish, LH |
| 75553A | Moulding, Roof Drip Side Finish, Rear RH |
| 75554A | Moulding, Roof Drip Side Finish, Rear LH |
| 75555D | Moulding, Roof Drip Side Finish, Center RH |
| 75556C | Moulding, Roof Drip Side Finish, Center LH |
| 75557C | Moulding, Roof Drip Side Finish, Center NO.2 RH |
| 75558C | Moulding, Roof Drip Side Finish, Center NO.2 LH |
| 75561 | Clip, Roof Drip Side Finish Moulding, NO.1 |
| 75596 | Cover, Roof Drip Side Finish Moulding Joint, RH |
| 75597 | Cover, Roof Drip Side Finish Moulding Joint, LH |
| 75601A | Moulding Sub-assy, Front Fender, RH |
| 75602A | Moulding Sub-assy, Front Fender, LH |
| 75605A | Moulding Sub-assy, Quarter Outside, RH |
| 75606A | Moulding Sub-assy, Quarter Outside, LH |
| 75696 | Pad, Body Outside Moulding, NO.1 |
| 75696A | Pad, Body Outside Moulding |
| 75698A | Pad, Body Outside Moulding, NO.3 |
| 75711B | Moulding, Front Door Belt, RH |
| 75712B | Moulding, Front Door Belt, LH |
| 75721A | Moulding, Rear Door Belt, RH |
| 75722A | Moulding, Rear Door Belt, LH |
| 75755A | Moulding, Front Door Window Frame, RH(CENTER PILLAR SIDE) |
| 75756D | Moulding, Front Door Window Frame, LH(CENTER PILLAR SIDE) |
| 75761B | Moulding, Rear Door Window Frame, RH(CENTER PILLAR SIDE) |
| 75762B | Moulding, Rear Door Window Frame, LH(CENTER PILLAR SIDE) |
| 75767A | Pad, Rear Door Moulding, NO.1 |
| 75770 | Moulding Assy, Hood, Front |
| 75774E | Spacer, Hood Moulding |
| 75777E | Pad, Hood Front Moulding |
| 75781 | Moulding, Quarter Window, Lower RH |
| 75781A | Clip, Quarter Window Moulding |
| 75782 | Moulding, Quarter Window, Lower LH |
| 75792 | Clip, Door Window Frame Moulding |
| 75793 | Pad, Front Door Outside Moulding, Upper |
| 75797C | Pad, Rear Door Outside Moulding, Upper |
| 75850A | Moulding Assy, Body Rocker Panel, RH |
| 75857 | Cover, Rocker Panel Moulding, RH |
| 75858 | Cover, Rocker Panel Moulding, LH |
| 75860A | Moulding Assy, Body Rocker Panel, LH |
| 75867A | Clip, Rocker Panel Moulding |
| 75873 | Moulding, Quarter Panel Wheel Opening, RH |
| 75874 | Moulding, Quarter Panel Wheel Opening, LH |
| 76521A | Protector, Front Fender Garnish |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
