Toyota Land Cruiser

2024-02 → present · chassis TJH250 · catalogue 781490 · United States

Supported model Data version 2024-02
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Interior Lamp

20 part groups · 2 illustrations

Illustrations

Figure 81B89A 81B89A 2024-02 → — Figure 81B89B 81B89B 2024-02 → —

Part groups

PNCDescription
81080D Lamp Assy, Front Door Inside Handle Illumination, RH
81080E Lamp Assy, Front Door Inside Handle Illumination, LH
81080F Lamp Assy, Rear Door Inside Handle Illumination, RH
81080G Lamp Assy, Rear Door Inside Handle Illumination, LH
81080J Lamp Assy, Interior Illumination, NO.1
81080M Lamp Assy, Interior Illumination, NO.1
81080N Lamp Assy, Interior Illumination, NO.1
81080V Lamp Assy, Interior Illumination, NO.2
81080W Lamp Assy, Interior Illumination, NO.3
81081 Lamp Sub-assy, Interior Illumination
81230 Lamp Assy, Courtesy
81240 Lamp Assy, Room, NO.1
81240K Clip, Room Lamp
81260A Lamp Assy, Map
81260M Clip, Room Lamp
81330 Lamp Assy, Luggage Compartment, NO.1
81340 Lamp Assy, Vanity
81362B Lens, Interior Illumination Lamp
81380D Lamp Assy, Step
81380E Bulb (FOR STEP LAMP)
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
