Toyota Land Cruiser
1969-03 → 1980-07 · chassis BJ40,FJ4#,55 · catalogue 791410 · United States
Discontinued model
Data version 1985-05
Switch & Relay & Computer
88 part groups · 12 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 27700 | Regulator Assy, Generator |
| 28300 | Relay Assy, Starter |
| 28550 | Controller Assy, Glow Plug |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 81402 | Socket Sub-assy, Inspection Lamp, NO.1 |
| 81908 | Bracket Sub-assy, Flasher |
| 81980 | Flasher Assy, Turn Signal |
| 81981 | Flasher Assy, Hazard Warning Signal |
| 81990 | Relay Assy, Turn Signal |
| 82600 | Block Assy, Fuse |
| 82600F | Fuse, Fuse Block |
| 82611 | Cover, Fuse Block |
| 82612 | Insulator, Fuse Block Terminal |
| 82612A | Insulator, Fuse Block Terminal, B |
| 82650 | Breaker Assy, Wiring Circuit, NO.1 |
| 83181 | Detector Assy, Speed |
| 83260 | Relay Assy, Speed Marker |
| 83320 | Gage Assy, Fuel Sender |
| 83361 | Gasket, Fuel Sender Gage |
| 83390 | Switch Assy, Vacuum Warning |
| 83391 | Switch, Vacuum |
| 83420 | Gage Assy, Water Temperature Sender |
| 83520 | Gage Assy,Oil Pressure Sender |
| 83540 | Switch Assy, Brake Warning (FOR TANDEM MASTER CYLINDER) |
| 84001 | Switch Assy, Magnet |
| 84095 | Bracket Sub-assy, Hand Brake Signal Switch |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84110A | Bolt OR Nut, Light Control Switch Set |
| 84110B | Bulb, Light Control Switch |
| 84111 | Knob, Light Control Switch |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84160 | Switch Assy, Room Lamp |
| 84161 | Knob, Room Lamp Switch |
| 84201 | Bracket Sub-assy, Back-up Lamp Switch |
| 84210 | Switch Assy, Back-up Lamp |
| 84210T | Sensor Assy, Shift Point |
| 84220 | Switch Assy, Transfer Lever Select |
| 84310 | Switch Assy, Turn Signal |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84330A | Bolt OR Nut, Hazard Warning Signal Switch Set |
| 84331 | Knob, Hazard Warning Signal Switch |
| 84340 | Switch Assy, Stop Lamp |
| 84380 | Switch Assy, Brake Warning Test |
| 84450 | Switch Assy, Ignition OR Starter |
| 84510 | Switch Assy, Starter |
| 84521 | Switch, Glow Plug |
| 84620 | Switch Assy, Front Drive Indicator |
| 84650 | Switch Assy, Windshield Wiper |
| 84650A | Bolt OR Nut, Windshield Wiper Switch Set |
| 84651 | Knob, Windshield Wiper Switch |
| 84660 | Switch Assy, Front Drive |
| 84660A | Nut, Front Drive Switch |
| 84660B | Bulb, Front Drive Switch |
| 84730 | Switch Assy, Heater Blower |
| 84731 | Knob, Heater Blower Switch |
| 84732 | Retainer, Heater Blower Switch Lever |
| 84830 | Switch Assy, Tail Gate Control |
| 84860 | Switch Assy, Tail Gate Remote Control |
| 84880 | Switch Assy, Tail Gate Safety |
| 85430 | Valve, Outer Vent Control |
| 85440 | Solenoid Assy, Front Drive |
| 85500 | Lighter Assy, Cigarette |
| 85540 | Resistance Assy, Cigarette Lighter |
| 85550 | Resistor Assy, Pilot Lamp |
| 85915 | Relay, Main |
| 85917 | Relay, Front Drive |
| 85926 | Relay, Headlamp Dimmer |
| 85927 | Relay, Cooling Fan |
| 85990 | Relay OR Computer Assy, Seat Belt Warning |
| 85999 | Bracket, Combination Relay |
| 85999A | Bracket, Relay, NO.2 |
| 86530 | Relay Assy, Horn |
| 86650 | Buzzer Assy, Vacuum Indicator |
| 86680 | Buzzer Assy, Un-lock Warning OR Seat Belt Warning |
| 87298 | Bracket OR Panel, Heater Switch |
| 89423 | Sensor, Temperature Detect Egr |
| 89423A | Sensor, Manifold Temperature |
| 89425 | Sensor, Exhaust Gas Temperature |
| 89427 | Switch, Temperature Detect |
| 89429 | Sensor, Oil Temperature |
| 89434 | Bracket, Manifold Temperature Sensor |
| 89445 | Detector, Maintenance Interval |
| 89448 | Bracket, Maintenance Interval Detector |
| 89453 | Switch, Throttle Position (FOR T.C.S.) |
| 89459 | Bracket, Throttle Position |
| 89550 | Computer Assy, Emission Control |
| 89559 | Bracket, Emission Control Computer |
| 89620 | Igniter Assy |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
