Toyota Tundra
1999-02 → 2006-10 · chassis GSK30,UCK3#,4#,VCK30,40 · catalogue 841420 · United States
Discontinued model
Data version 2007-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 15690 — Valve Assy, Oil Cooler Relief | ||||
| 15695-50010 |
Valve Assy, Oil Cooler Relief
1999-02 → 2002-08
ended
|
2UZFE UCK30,40 | — | |
| 15695-62030 |
Valve Assy, Oil Cooler Relief
1999-02 → 2002-08
ended
|
5VZFE VCK40;5VZFE VCK30 5F | — | |
| 15695-50010 |
Valve Assy, Oil Cooler Relief
2002-08 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 15695-62030 |
Valve Assy, Oil Cooler Relief
2002-08 → 2004-08
ended
|
5VZFE VCK40;5VZFE VCK30 5F | — | |
| 15695-50010 |
Valve Assy, Oil Cooler Relief
2004-08 → —
|
2UZFE UCK3#,4# | — | |
| 15710 — Cooler Assy, Oil | ||||
| 15710-50030 |
Cooler Assy, Oil
1999-02 → 2002-08
ended
|
2UZFE UCK30,40 | — | |
| 15710-50030 |
Cooler Assy, Oil
2002-08 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 15710-31010 |
Cooler Assy, Oil
2004-08 → —
|
1GRFE GSK30 | — | |
| 15710-50030 |
Cooler Assy, Oil
2004-08 → —
|
2UZFE UCK3#,4# | — | |
| 15710B — Ring, O(FOR OIL COOLER) | ||||
| 90301-67004 |
Ring, O(FOR OIL COOLER)
1999-02 → 2002-08
ended
|
5VZFE VCK40;5VZFE VCK30 5F | — | |
| 90301-67004 |
Ring, O(FOR OIL COOLER)
2002-08 → 2004-08
ended
|
2UZFE UCK30,40 | — | |
| 90301-67004 |
Ring, O(FOR OIL COOLER)
2002-08 → 2004-08
ended
|
5VZFE VCK40;5VZFE VCK30 5F | — | |
| 90301-67004 |
Ring, O(FOR OIL COOLER)
2003-10 → 2004-08
ended
|
2UZFE UCK31,41 | — | |
| 90301-67004 |
Ring, O(FOR OIL COOLER)
2004-08 → 2006-12
ended
|
2UZFE UCK3#,4# | — | |
| 90301-67004 |
Ring, O(FOR OIL COOLER)
2004-08 → —
|
1GRFE GSK30 | — | |
| 15767 — Pipe, Oil Cooler | ||||
| 15767-50070 |
Pipe, Oil Cooler
1999-02 → 2002-08
ended
|
2UZFE UCK30,40 | — | |
| 15767-0F010 note |
Pipe, Oil Cooler
2003-05 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 15767-50110 note |
Pipe, Oil Cooler
2002-08 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 15767-0F011 |
Pipe, Oil Cooler
2004-08 → —
|
2UZFE UCK3#,4# | — | |
| 15767B — Hose, Water By-pass, NO.4 | ||||
| 16281-50030 note |
Hose, Water By-pass, NO.4
1999-02 → 2002-08
ended
|
2UZFE UCK30,40 | — | |
| 16281-0F010 note |
Hose, Water By-pass, NO.4
2003-05 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 16281-50030 note |
Hose, Water By-pass, NO.4
2002-08 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 16281-0F010 |
Hose, Water By-pass, NO.4
2004-08 → —
|
2UZFE UCK3#,4# | — | |
| 15767C — Hose, Water By-pass, NO.5 | ||||
| 16282-50070 note |
Hose, Water By-pass, NO.5
1999-02 → 2002-08
ended
|
2UZFE UCK30,40 | — | |
| 16282-0F010 note |
Hose, Water By-pass, NO.5
2003-05 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 16282-50070 note |
Hose, Water By-pass, NO.5
2002-08 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 16282-0F010 |
Hose, Water By-pass, NO.5
2004-08 → —
|
2UZFE UCK3#,4# | — | |
| 15777 — Hose, Oil Cooler | ||||
| 15777-50060 |
Hose, Oil Cooler
1999-02 → 2002-08
ended
|
2UZFE UCK30,40 | — | |
| 15777-62020 |
Hose, Oil Cooler
1999-02 → 2002-08
ended
|
5VZFE VCK40;5VZFE VCK30 5F | — | |
| 15777-50060 |
Hose, Oil Cooler
2002-08 → 2004-08
ended
|
2UZFE UCK3#,4# | — | |
| 15777-62020 |
Hose, Oil Cooler
2002-08 → 2004-08
ended
|
5VZFE VCK40;5VZFE VCK30 5F | — | |
| 15777-31010 |
Hose, Oil Cooler
2004-08 → —
|
1GRFE GSK30 | — | |
| 15777-50060 |
Hose, Oil Cooler
2004-08 → —
|
2UZFE UCK3#,4# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
