Toyota Tundra
1999-02 → 2006-10 · chassis GSK30,UCK3#,4#,VCK30,40 · catalogue 841420 · United States
Discontinued model
Data version 2007-04
Seat Belt
45 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 61841A | Bracket, Shoulder Belt Anchor, RH |
| 61842B | Bracket, Shoulder Belt Anchor, LH |
| 73015A | Bracket Sub-assy, Belt Outer Anchor, RH |
| 73016A | Bracket Sub-assy, Belt Outer Anchor, LH |
| 73030 | Belt Assy, NO.1 Seat Lap, Center W/Inner RH |
| 73040 | Belt Assy, NO.1 Seat Lap, Center W/Inner LH |
| 73131A | Bracket, Seat Belt |
| 73135 | Cover, Shoulder Belt Anchorage Plate |
| 73140 | Belt Assy, Front Seat Lap Type, LH |
| 73160A | Seat Belt Assy, Front Center, RH |
| 73160C | Belt Assy, Front Center Seat, RH |
| 73178A | Cap, Seat Belt Anchor Cover |
| 73178C | Cap, Seat Belt Anchor Cover |
| 73200A | Adjuster Assy, Front Shoulder Belt Anchor |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73223B | Cover, Front Seat Belt Retractor, RH |
| 73223C | Clip, Front Seat Belt Retractor Cover |
| 73224 | Cover, Front Seat Belt Retractor, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73233 | Cover, Lap Belt Outer Anchor |
| 73233A | Cover, Lap Belt Outer Anchor, Rear NO.1 Seat |
| 73233C | Cover, Lap Belt Outer Anchor, LH |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73240A | Belt Assy, Front Seat Inner LH |
| 73252 | Cover, Shoulder Belt Anchor Adjust, RH |
| 73253 | Cover, Shoulder Belt Anchor Adjust, LH |
| 73297B | Cover, Quarter Trim Belt Hole, RH |
| 73298B | Cover, Quarter Trim Belt Hole, LH |
| 73343 | Guide, Rear Seat Shoulder Belt, RH |
| 73345 | Guide, Rear Seat Shoulder Belt, Center |
| 73350C | Belt Assy, Rear Seat, Outer Center |
| 73360 | Belt Assy, Rear Seat 3 Point Type, Outer RH |
| 73360B | Belt Assy, Rear Seat, Outer |
| 73370 | Belt Assy, Rear Seat 3 Point Type, Outer LH |
| 73370B | Belt Assy, Rear Seat, Outer |
| 73373 | Cover, Rear Seat Shoulder Belt |
| 73373H | Cover, Front Seat Shoulder Belt |
| 73380C | Belt Assy, Rear NO.1 Seat, Inner RH |
| 73390A | Belt Assy, Rear Seat, Inner |
| 73390C | Belt Assy, Rear NO.1 Seat, Inner LH |
| 73709 | Bracket Sub-assy, Tether Anchor |
| 73717 | Cover, Child Restraint Seat Tether Anchor |
| 73719 | Bracket, Child Restraint Seat Tether Anchor |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
