Toyota Tundra
2006-11 → 2021-10 · chassis GSK5#,UCK5#,UPK5#,USK5# · catalogue 841430 · United States
Supported model
Data version 2023-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 15600 — Filter Assy, Oil | ||||
| 90915-20004 |
Filter Assy, Oil
2006-11 → 2009-04
ended
|
2UZFE UCK5# | — | |
| 15609 — Bracket Sub-assy, Oil Filter | ||||
| 15609-50110 |
Bracket Sub-assy, Oil Filter
2006-11 → 2009-04
ended
|
2UZFE UCK5# | — | |
| 15670-31010 |
Bracket Sub-assy, Oil Filter
2006-11 → 2009-04
ended
|
1GRFE GSK5# | — | |
| 15670-31010 |
Bracket Sub-assy, Oil Filter
2009-04 → 2010-10
ended
|
1GRFE GSK5# | — | |
| 15692 — Gasket, Oil Filter Bracket | ||||
| 15692-31010 |
Gasket, Oil Filter Bracket
2006-11 → 2009-04
ended
|
1GRFE GSK5# | — | |
| 15692-50020 |
Gasket, Oil Filter Bracket
2006-11 → 2009-04
ended
|
2UZFE UCK5# | — | |
| 15692-31010 |
Gasket, Oil Filter Bracket
2009-04 → 2010-10
ended
|
1GRFE GSK5# | — | |
| 15692-31030 |
Gasket, Oil Filter Bracket
2010-10 → 2013-08
ended
|
1GRFE GSK5# | — | |
| 15692-31030 |
Gasket, Oil Filter Bracket
2013-08 → 2014-09
ended
|
1GRFE GSK51 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
