Toyota Tundra
2006-11 → 2021-10 · chassis GSK5#,UCK5#,UPK5#,USK5# · catalogue 841430 · United States
Supported model
Data version 2023-05
Console Box & Bracket
30 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 55539A | Cover, Spare Switch Hole |
| 55620E | Holder Assy, Instrument Panel Cup |
| 55630A | Holder, Rear Console Box, Cup |
| 58804A | Panel Sub-assy, Console, Upper |
| 58805C | Panel Sub-assy, Console, Upper Rear |
| 58811A | Box, Console, Front |
| 58811D | Clip(FOR CONSOLE BOX) |
| 58815A | Carpet, Console Box |
| 58820A | Box Assy, Console Compartment |
| 58822A | Panel, Console, Upper Rear |
| 58823B | Box, Console Compartment |
| 58825B | Pocket, Console Box |
| 58833B | Garnish, Console Upper Panel, NO.1 |
| 58844 | Bezel, Console Box |
| 58859A | Hook, Console Box Holder |
| 58860A | Register Assy, Console Box |
| 58861C | Duct, Console Box, NO.1 |
| 58865A | Lens, Front Console Box, NO.1 |
| 58871 | Cushion, Console Box |
| 58871A | Cushion, Console Box, NO.2 |
| 58903A | Panel Sub-assy, Console Rear End |
| 58905 | Door Sub-assy, Console Compartment |
| 58910C | Box Assy, Console, Rear |
| 58916 | Mat, Box Bottom |
| 58917A | Cover, Console Box, Rear |
| 58923A | Panel, Console Rear End |
| 58925A | Pocket, Console Box, Rear |
| 58959B | Cushion, Console Compartment Door |
| 58971D | Lever, Console Compartment Door Lock |
| 58981B | Retainer, Console Mounting, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
