Toyota Tundra
2006-11 → 2021-10 · chassis GSK5#,UCK5#,UPK5#,USK5# · catalogue 841430 · United States
Supported model
Data version 2023-05
Interior Lamp
14 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 81080J | Lamp Assy, Interior Illumination, NO.1 |
| 81205B | Bulb, Ash Receptacle Lamp |
| 81230 | Lamp Assy, Courtesy |
| 81230B | Bulb(FOR COURTESY LAMP) |
| 81240 | Lamp Assy, Room, NO.1 |
| 81240B | Bulb, Room Lamp, NO.1 |
| 81260 | Lamp Assy, Glove Box |
| 81260C | Bulb(FOR MAP LAMP) |
| 81340B | Bulb (FOR VANITY LAMP) |
| 81360B | Bulb, Step OR Spot Lamp |
| 81391E | Holder, Lens, Front RH |
| 81391F | Holder, Lens, Front LH |
| 81490B | Bulb (FOR FOOT LAMP) |
| 81870D | Lamp Assy, Key Cylinder |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
