Toyota Sequoia
2000-09 → 2007-11 · chassis UCK35,45 · catalogue 842410 · United States
Discontinued model
Data version 2008-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 19100P — Plug, Spark | ||||
| 90919-01166 note |
Plug, Spark
2000-09 → 2004-08
ended
|
2UZFE UCK35,45 | — | |
| 90080-91180 note |
Plug, Spark
2004-08 → —
|
2UZFE UCK35,45 | — | |
| 90919-01210 note |
Plug, Spark
2004-08 → —
|
2UZFE UCK35,45 | — | |
| 19500 — Coil Assy, Ignition | ||||
| 90919-02230 |
Coil Assy, Ignition
2000-09 → 2003-08
ended
|
2UZFE UCK35,45 | — | |
| 90919-02249 note |
Coil Assy, Ignition
2003-08 → 2004-08
ended
|
2UZFE UCK35,45 | — | |
| 90080-19027 note |
Coil Assy, Ignition
2004-08 → —
|
2UZFE UCK35,45 | — | |
| 90919-02249 note |
Coil Assy, Ignition
2004-08 → —
|
2UZFE UCK35,45 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
