Toyota Sequoia
2000-09 → 2007-11 · chassis UCK35,45 · catalogue 842410 · United States
Discontinued model
Data version 2008-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 41110R — Plug, Breather (FOR FRONT DIFFERENTIAL) | ||||
| 90930-03136 |
Plug, Breather (FOR FRONT DIFFERENTIAL)
2000-09 → 2004-08
ended
|
UCK45 | — | |
| 90930-03136 note |
Plug, Breather (FOR FRONT DIFFERENTIAL)
2004-08 → —
|
UCK45 | — | |
| 90930-03159 note |
Plug, Breather (FOR FRONT DIFFERENTIAL)
2004-08 → —
|
UCK45 | — | |
| 41507A — Tube, Front Differential Lock Actuator Breather, NO.2 | ||||
| 41507-34021 |
Tube, Front Differential Lock Actuator Breather, NO.2
2000-09 → 2004-08
ended
|
UCK45 | — | |
| 41507-34021 |
Tube, Front Differential Lock Actuator Breather, NO.2
2004-08 → —
|
UCK45 | — | |
| 41507B — Tube, Front Differential Lock Actuator Breather | ||||
| 90445-08349 |
Tube, Front Differential Lock Actuator Breather
2000-09 → 2004-08
ended
|
UCK45 | — | |
| 90445-08349 |
Tube, Front Differential Lock Actuator Breather
2004-08 → —
|
UCK45 | — | |
| 41531F — Hose, Front Differential Vacuum, NO.1 | ||||
| 90445-14181 note |
Hose, Front Differential Vacuum, NO.1
2000-09 → 2004-08
ended
|
UCK45 | — | |
| 90445-14181 note |
Hose, Front Differential Vacuum, NO.1
2004-08 → —
|
UCK45 | — | |
| 41531G — Hose, Front Differential Vacuum, NO.2 | ||||
| 90445-14174 note |
Hose, Front Differential Vacuum, NO.2
2000-09 → 2004-08
ended
|
UCK45 | — | |
| 90445-14174 note |
Hose, Front Differential Vacuum, NO.2
2004-08 → —
|
UCK45 | — | |
| 41533 — Tube, Front Differential Breather | ||||
| 41533-34010 |
Tube, Front Differential Breather
2000-09 → 2004-08
ended
|
UCK45 | — | |
| 41533-34010 |
Tube, Front Differential Breather
2004-08 → —
|
UCK45 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
