Toyota Sequoia
2000-09 → 2007-11 · chassis UCK35,45 · catalogue 842410 · United States
Discontinued model
Data version 2008-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 47101 — Pedal Sub-assy, Brake | ||||
| 47101-34081 |
Pedal Sub-assy, Brake
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 47101-34081 |
Pedal Sub-assy, Brake
2004-08 → —
|
UCK35,45 | — | |
| 47101A — Spring(FOR BRAKE PEDAL RETURN) | ||||
| 90905-07023 |
Spring(FOR BRAKE PEDAL RETURN)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90905-07023 |
Spring(FOR BRAKE PEDAL RETURN)
2004-08 → —
|
UCK35,45 | — | |
| 47101B — Bush(FOR BRAKE PEDAL) | ||||
| 90386-14015 |
Bush(FOR BRAKE PEDAL)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90386-14015 |
Bush(FOR BRAKE PEDAL)
2004-08 → —
|
UCK35,45 | — | |
| 47101K — Cushion(FOR PARKING LOCK CABLE) | ||||
| 90541-06049 |
Cushion(FOR PARKING LOCK CABLE)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90541-06049 |
Cushion(FOR PARKING LOCK CABLE)
2004-08 → —
|
UCK35,45 | — | |
| 47112 — Lever, Brake Pedal | ||||
| 47112-34031 |
Lever, Brake Pedal
2000-09 → 2000-12
ended
|
UCK35,45 4HC | — | |
| 47112-34031 |
Lever, Brake Pedal
2000-12 → 2004-08
ended
|
UCK35,45 | — | |
| 47112-34031 |
Lever, Brake Pedal
2004-08 → —
|
UCK35,45 | — | |
| 47121 — Pad, Brake Pedal | ||||
| 47121-50010 |
Pad, Brake Pedal
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 47121-50010 |
Pad, Brake Pedal
2004-08 → —
|
UCK35,45 | — | |
| 47124A — Collar(FOR BRAKE PEDAL SHAFT) | ||||
| 47144-34010 |
Collar(FOR BRAKE PEDAL SHAFT)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 47144-34010 |
Collar(FOR BRAKE PEDAL SHAFT)
2004-08 → —
|
UCK35,45 | — | |
| 47124E — Collar, Brake Pedal Shaft, NO.2 | ||||
| 90387-08156 |
Collar, Brake Pedal Shaft, NO.2
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90387-08156 |
Collar, Brake Pedal Shaft, NO.2
2004-08 → —
|
UCK35,45 | — | |
| 47125C — Collar(FOR BRAKE PEDAL BRACKET) | ||||
| 90387-08157 |
Collar(FOR BRAKE PEDAL BRACKET)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90387-08157 |
Collar(FOR BRAKE PEDAL BRACKET)
2004-08 → —
|
UCK35,45 | — | |
| 47130 — Link Assy, Brake Pedal | ||||
| 47130-60010 note |
Link Assy, Brake Pedal
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 4710A-34010 note |
Link Assy, Brake Pedal
2005-01 → —
|
UCK35,45 | — | |
| 47130-60010 note |
Link Assy, Brake Pedal
2004-08 → 2005-01
ended
|
UCK35,45 | — | |
| 47130-60011 note |
Link Assy, Brake Pedal
2005-01 → —
|
UCK35,45 | — | |
| 47130A — Pin, Brake Pedal Link | ||||
| 90249-06171 note |
Pin, Brake Pedal Link
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90249-06172 note |
Pin, Brake Pedal Link
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90249-06171 note |
Pin, Brake Pedal Link
2004-08 → 2005-01
ended
|
UCK35,45 | — | |
| 90249-06172 note |
Pin, Brake Pedal Link
2004-08 → 2005-01
ended
|
UCK35,45 | — | |
| 47130B — Ring E, Brake Pedal Link Pin | ||||
| 96160-00400 |
Ring E, Brake Pedal Link Pin
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 96160-00400 |
Ring E, Brake Pedal Link Pin
2004-08 → —
|
UCK35,45 | — | |
| 47131 — Cushion(FOR STOP LAMP SWITCH) | ||||
| 47131-34010 note |
Cushion(FOR STOP LAMP SWITCH)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90541-06036 note |
Cushion(FOR STOP LAMP SWITCH)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 47131-34010 note |
Cushion(FOR STOP LAMP SWITCH)
2004-08 → —
|
UCK35,45 | — | |
| 90541-06036 note |
Cushion(FOR STOP LAMP SWITCH)
2004-08 → —
|
UCK35,45 | — | |
| 47264A — Pin(FOR PUSH ROD) | ||||
| 90240-06023 |
Pin(FOR PUSH ROD)
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 90240-06023 |
Pin(FOR PUSH ROD)
2004-08 → —
|
UCK35,45 | — | |
| 55106 — Support Sub-assy, Brake Pedal | ||||
| 55106-34030 |
Support Sub-assy, Brake Pedal
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 55106-34030 |
Support Sub-assy, Brake Pedal
2004-08 → —
|
UCK35,45 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
