Toyota Sequoia
2000-09 → 2007-11 · chassis UCK35,45 · catalogue 842410 · United States
Discontinued model
Data version 2008-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 89741 — Receiver, Door Control | ||||
| 89741-0C010 |
Receiver, Door Control
2000-09 → 2003-09
ended
|
UCK35,45 4HC | — | |
| 89741-0C030 |
Receiver, Door Control
2003-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89741-0C030 |
Receiver, Door Control
2004-08 → —
|
UCK35,45 | — | |
| 89742 — Transmitter, Door Control | ||||
| 89742-0C010 |
Transmitter, Door Control
2000-09 → 2003-09
ended
|
UCK35,45 4HC | — | |
| 89742-0C030 |
Transmitter, Door Control
2003-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89742-0C030 |
Transmitter, Door Control
2004-08 → —
|
UCK35,45 | — | |
| 89745 — Battery, Transmitter | ||||
| 89745-48030 |
Battery, Transmitter
2003-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89745-50010 |
Battery, Transmitter
2000-09 → 2003-09
ended
|
UCK35,45 4HC | — | |
| 89745-48030 |
Battery, Transmitter
2004-08 → —
|
UCK35,45 | — | |
| 89747 — Buzzer, Wireless Door Lock | ||||
| 89747-51010 |
Buzzer, Wireless Door Lock
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89747-51010 |
Buzzer, Wireless Door Lock
2004-08 → —
|
UCK35,45 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
