Toyota Sequoia
2000-09 → 2007-11 · chassis UCK35,45 · catalogue 842410 · United States
Discontinued model
Data version 2008-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 89170 — Sensor Assy, Airbag | ||||
| 89170-0C030 |
Sensor Assy, Airbag
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89170-0C040 note |
Sensor Assy, Airbag
2000-09 → 2002-09
ended
|
UCK35,45 4HC | — | |
| 89170-0C070 note |
Sensor Assy, Airbag
2002-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89170-0C130 |
Sensor Assy, Airbag
2004-08 → 2006-08
ended
|
UCK35,45 | — | |
| 89170-0C140 note |
Sensor Assy, Airbag
2004-08 → 2006-05
ended
|
UCK35,45 | — | |
| 89170-0C141 note |
Sensor Assy, Airbag
2006-06 → 2006-08
ended
|
UCK35,45 | — | |
| 89170-0C141 |
Sensor Assy, Airbag
2006-08 → —
|
UCK35,45 | — | |
| 89173A — Sensor, Airbag, Front RH | ||||
| 89173-39295 |
Sensor, Airbag, Front RH
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89173-09200 |
Sensor, Airbag, Front RH
2004-08 → —
|
UCK35,45 | — | |
| 89174A — Sensor, Airbag, Front LH | ||||
| 89174-39165 |
Sensor, Airbag, Front LH
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89174-09040 |
Sensor, Airbag, Front LH
2004-08 → —
|
UCK35,45 | — | |
| 89860 — Sensor Assy, Side Airbag, RH | ||||
| 89860-0C010 |
Sensor Assy, Side Airbag, RH
2000-09 → 2002-09
ended
|
UCK35,45 4HC | — | |
| 89860-0C020 |
Sensor Assy, Side Airbag, RH
2002-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89860-0C040 |
Sensor Assy, Side Airbag, RH
2004-08 → —
|
UCK35,45 | — | |
| 89860A — Sensor Assy, Side Airbag, LH | ||||
| 89830-0C010 |
Sensor Assy, Side Airbag, LH
2000-09 → 2002-09
ended
|
UCK35,45 4HC | — | |
| 89830-0C020 |
Sensor Assy, Side Airbag, LH
2002-09 → 2004-08
ended
|
UCK35,45 | — | |
| 89830-0C040 |
Sensor Assy, Side Airbag, LH
2004-08 → —
|
UCK35,45 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
