Toyota Sequoia
2000-09 → 2007-11 · chassis UCK35,45 · catalogue 842410 · United States
Discontinued model
Data version 2008-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86101 — Cord Sub-assy, Antenna | ||||
| 86101-AF010 |
Cord Sub-assy, Antenna
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 86101-0C010 |
Cord Sub-assy, Antenna
2004-08 → —
|
UCK35,45 | — | |
| 86300 — Antenna Assy, W/Holder | ||||
| 86300-AF010 note |
Antenna Assy, W/Holder
2000-09 → 2004-08
ended
|
UCK35,45 | — | |
| 86300-AF020 note |
Antenna Assy, W/Holder
2002-09 → 2004-08
ended
|
UCK45 | — | |
| 86300-0C020 |
Antenna Assy, W/Holder
2004-08 → —
|
UCK35,45 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
