Toyota Sequoia
2000-09 → 2007-11 · chassis UCK35,45 · catalogue 842410 · United States
Discontinued model
Data version 2008-05
Side Member
70 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 55713C | Panel, Cowl Top Side, RH |
| 55714C | Panel, Cowl Top Side, LH |
| 58169E | Retainer, Rear Heater Mounting |
| 58169G | Retainer, Rear Heater Mounting |
| 61037A | Reinforcement Sub-assy, Center Body Pillar, RH |
| 61038A | Reinforcement Sub-assy, Center Body Pillar, LH |
| 61108A | Reinforce Sub-assy, Front Body Pillar, Lower RH |
| 61109A | Reinforce Sub-assy, Front Body Pillar, Lower LH |
| 61131 | Pillar, Front Body, Upper Outer RH |
| 61132 | Pillar, Front Body, Upper Outer LH |
| 61161 | Pillar, Front Body, Upper Inner RH |
| 61162 | Pillar, Front Body, Upper Inner LH |
| 61183A | Bracket, Instrument Panel Side, NO.2 RH |
| 61211 | Rail, Roof Side, Outer RH |
| 61212 | Rail, Roof Side, Outer LH |
| 61231 | Rail, Roof Side, Inner RH |
| 61232 | Rail, Roof Side, Inner LH |
| 61261 | Channel, Roof Drip, RH |
| 61262 | Channel, Roof Drip, LH |
| 61263B | Channel, Roof Drip Side, Front RH |
| 61264A | Channel, Roof Drip Side, Front LH |
| 61305 | Reinforce Sub-assy, Center Body Pillar, Lower RH |
| 61306 | Reinforce Sub-assy, Center Body Pillar, Lower LH |
| 61311B | Pillar, Center Body, Outer RH |
| 61312B | Pillar, Center Body, Outer LH |
| 61413C | Reinforcement, Rocker Panel, NO.2 RH |
| 61414C | Reinforcement, Rocker Panel, NO.2 LH |
| 61418A | Reinforcement, Rocker Panel, RH |
| 61419A | Reinforcement, Rocker Panel, LH |
| 61517B | Reinforcement, Quarter Lock Pillar, RH |
| 61518A | Reinforcement, Quarter Lock Pillar, LH |
| 61603C | Panel Sub-assy, Quarter Wheel House, RH |
| 61604D | Panel Sub-assy, Quarter Wheel House, LH |
| 61607E | Panel, Quarter Wheel House, Inner RH |
| 61608D | Panel, Quarter Wheel House, Inner LH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61615F | Reinforcement, Quarter Panel, Outer RH |
| 61616E | Reinforcement, Quarter Panel, Outer LH |
| 61621D | Trough, Back Door Opening, RH |
| 61622D | Trough, Back Door Opening, LH |
| 61623B | Trough, Back Door Opening, Rear RH |
| 61624B | Trough, Back Door Opening, Rear LH |
| 61625G | Extension, Quarter Panel, Rear RH |
| 61626G | Extension, Quarter Panel, Rear LH |
| 61627E | Extension, Quarter Panel, Rear Lower RH |
| 61628D | Extension, Quarter Panel, Rear Lower LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61633A | Panel, Quarter Wheel House, Inner RH |
| 61634A | Panel, Quarter Wheel House, Inner LH |
| 61703H | Reinforcement Sub-assy, Roof Side, Inner RH |
| 61704J | Reinforcement Sub-assy, Roof Side, Inner LH |
| 61711 | Panel, Roof Side, Outer RH |
| 61712 | Panel, Roof Side, Outer LH |
| 61731B | Panel, Roof Side, Inner RH |
| 61732B | Panel, Roof Side, Inner LH |
| 61735A | Panel, Roof Side, Inner Rear RH |
| 61736A | Panel, Roof Side, Inner Rear LH |
| 61745A | Reinforcement, Back Door Opening, Lower RH |
| 61746A | Reinforcement, Back Door Opening, Lower LH |
| 61773A | Patch, Back Door Opening, Lower RH |
| 61774A | Patch, Back Door Opening, Lower LH |
| 61777D | Retainer, Back Door Side Stopper, RH |
| 61778J | Retainer, Back Door Side Stopper, LH |
| 61848A | Retainer, Quarter Panel, LH |
| 62381A | Weatherstrip, Roof Side Rail, RH |
| 62382A | Weatherstrip, Roof Side Rail, LH |
| 67865C | Weatherstrip, Center Pillar Upper End, RH |
| 67866B | Weatherstrip, Center Pillar Upper End, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
