Toyota Sequoia
2007-11 → 2021-12 · chassis UCK6#,UPK6#,USK6# · catalogue 842420 · United States
Supported model
Data version 2022-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 42311N — Nut(FOR REAR AXLE SHAFT RH) | ||||
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT RH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT RH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT RH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT RH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT RH)
2017-08 → —
|
USK6# HTWC | — | |
| 42311U — Bolt, Hub(FOR REAR AXLE RH) | ||||
| 90942-02077 |
Bolt, Hub(FOR REAR AXLE RH)
2007-11 → 2007-12
ended
|
UCK6#,USK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE RH)
2007-12 → 2009-04
ended
|
UCK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE RH)
2007-12 → 2012-08
ended
|
UPK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE RH)
2007-12 → 2017-08
ended
|
USK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE RH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE RH)
2017-08 → —
|
USK6# HTWC | — | |
| 42312B — Nut(FOR REAR AXLE SHAFT LH) | ||||
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT LH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT LH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT LH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT LH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90179-32007 |
Nut(FOR REAR AXLE SHAFT LH)
2017-08 → —
|
USK6# HTWC | — | |
| 42312E — Bolt, Hub(FOR REAR AXLE LH) | ||||
| 90942-02077 |
Bolt, Hub(FOR REAR AXLE LH)
2007-11 → 2007-12
ended
|
UCK6#,USK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE LH)
2007-12 → 2009-04
ended
|
UCK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE LH)
2007-12 → 2012-08
ended
|
UPK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE LH)
2007-12 → 2017-08
ended
|
USK6# | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE LH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90942-02083 |
Bolt, Hub(FOR REAR AXLE LH)
2017-08 → —
|
USK6# HTWC | — | |
| 42401 — Hub, Rear Axle, RH | ||||
| 43502-0C031 |
Hub, Rear Axle, RH
2010-02 → 2017-08
ended
|
USK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, RH
2010-02 → 2012-08
ended
|
UPK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, RH
2007-11 → 2009-08
ended
|
UPK6#,USK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 43502-34060 |
Hub, Rear Axle, RH
2009-09 → 2010-02
ended
|
UPK6#,USK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 43502-0C031 |
Hub, Rear Axle, RH
2017-08 → —
|
USK6# HTWC | — | |
| 42401E — Seal, Oil (FOR REAR AXLE HUB RH) | ||||
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2017-08 → —
|
USK6# HTWC | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2017-08 → —
|
USK6# HTWC | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB RH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 42401J — Seal, Dust(FOR REAR AXLE HUB RH) | ||||
| 90304-A0002 |
Seal, Dust(FOR REAR AXLE HUB RH)
2007-11 → 2017-08
ended
|
UCK6#,UPK6#,USK6# | — | |
| 90304-94001 |
Seal, Dust(FOR REAR AXLE HUB RH)
2017-09 → —
|
USK6# HTWC | — | |
| 90304-A0002 |
Seal, Dust(FOR REAR AXLE HUB RH)
2017-08 → 2017-09
ended
|
USK6# | — | |
| 42402 — Hub, Rear Axle, LH | ||||
| 43502-0C031 |
Hub, Rear Axle, LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, LH
2007-11 → 2009-08
ended
|
UPK6#,USK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, LH
2010-02 → 2012-08
ended
|
UPK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, LH
2010-02 → 2017-08
ended
|
USK6# | — | |
| 43502-34060 |
Hub, Rear Axle, LH
2009-09 → 2010-02
ended
|
UPK6#,USK6# | — | |
| 43502-0C031 |
Hub, Rear Axle, LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 43502-0C031 |
Hub, Rear Axle, LH
2017-08 → —
|
USK6# HTWC | — | |
| 42402E — Seal, Oil (FOR REAR AXLE HUB LH) | ||||
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2017-08 → —
|
USK6# HTWC | — | |
| 90312-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90316-A0002 note |
Seal, Oil (FOR REAR AXLE HUB LH)
2017-08 → —
|
USK6# HTWC | — | |
| 42402J — Seal, Dust(FOR REAR AXLE HUB LH) | ||||
| 90304-A0002 |
Seal, Dust(FOR REAR AXLE HUB LH)
2007-11 → 2017-08
ended
|
UCK6#,UPK6#,USK6# | — | |
| 90304-94001 |
Seal, Dust(FOR REAR AXLE HUB LH)
2017-09 → —
|
USK6# | — | |
| 90304-A0002 |
Seal, Dust(FOR REAR AXLE HUB LH)
2017-08 → 2017-09
ended
|
USK6# | — | |
| 42409E — Ring, O (FOR REAR AXLE BEARING RH) | ||||
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING RH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING RH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING RH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING RH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING RH)
2017-08 → —
|
USK6# HTWC | — | |
| 42409F — Ring, O (FOR REAR AXLE BEARING LH) | ||||
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING LH)
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING LH)
2007-11 → 2017-08
ended
|
USK6# | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING LH)
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING LH)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 90301-A0020 |
Ring, O (FOR REAR AXLE BEARING LH)
2017-08 → —
|
USK6# HTWC | — | |
| 42418B — Cap, Rear Hub Grease, RH | ||||
| 43514-34020 |
Cap, Rear Hub Grease, RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 43514-34020 |
Cap, Rear Hub Grease, RH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 43514-34020 |
Cap, Rear Hub Grease, RH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 43514-34020 |
Cap, Rear Hub Grease, RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 43514-34020 |
Cap, Rear Hub Grease, RH
2017-08 → —
|
USK6# HTWC | — | |
| 42418C — Cap, Rear Hub Grease, LH | ||||
| 43514-34020 |
Cap, Rear Hub Grease, LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 43514-34020 |
Cap, Rear Hub Grease, LH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 43514-34020 |
Cap, Rear Hub Grease, LH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 43514-34020 |
Cap, Rear Hub Grease, LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 43514-34020 |
Cap, Rear Hub Grease, LH
2017-08 → —
|
USK6# HTWC | — | |
| 42431 — Disc, Rear | ||||
| 42431-0C011 |
Disc, Rear
2007-11 → 2017-08
ended
|
UCK6#,UPK6#,USK6# | — | |
| 42431-0C011 |
Disc, Rear
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 42431-0C011 |
Disc, Rear
2017-08 → —
|
USK6# HTWC | — | |
| 42450A — Hub & Bearing Assy, Rear Axle, RH | ||||
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, RH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, RH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, RH
2017-08 → —
|
USK6# HTWC | — | |
| 42450B — Hub & Bearing Assy, Rear Axle, LH | ||||
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, LH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, LH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, LH
2017-08 → —
|
USK6# HTWC | — | |
| 42450-0C020 |
Hub & Bearing Assy, Rear Axle, LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 42491 — Plug, Shoe Adjusting Hole (FOR PARKING BRAKE) | ||||
| 47491-22020 |
Plug, Shoe Adjusting Hole (FOR PARKING BRAKE)
2007-11 → 2017-08
ended
|
UCK6#,UPK6#,USK6# | — | |
| 47491-22020 |
Plug, Shoe Adjusting Hole (FOR PARKING BRAKE)
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 47491-22020 |
Plug, Shoe Adjusting Hole (FOR PARKING BRAKE)
2017-08 → —
|
USK6# HTWC | — | |
| 43525D — Cap, Rear Wheel Adjusting Lock, RH | ||||
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, RH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, RH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, RH
2017-08 → —
|
USK6# HTWC | — | |
| 43525E — Cap, Rear Wheel Adjusting Lock, LH | ||||
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, LH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, LH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 43525-0C010 |
Cap, Rear Wheel Adjusting Lock, LH
2017-08 → —
|
USK6# HTWC | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
