Toyota Sequoia
2007-11 → 2021-12 · chassis UCK6#,UPK6#,USK6# · catalogue 842420 · United States
Supported model
Data version 2022-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 68710 — Hinge Assy, Front Door, Upper RH | ||||
| 68710-02020 |
Hinge Assy, Front Door, Upper RH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 68710-02020 |
Hinge Assy, Front Door, Upper RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 68710-02020 |
Hinge Assy, Front Door, Upper RH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 68710-02020 |
Hinge Assy, Front Door, Upper RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 68710-02020 |
Hinge Assy, Front Door, Upper RH
2017-08 → —
|
USK6# HTWC | — | |
| 68720 — Hinge Assy, Front Door, Upper LH | ||||
| 68720-02020 |
Hinge Assy, Front Door, Upper LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 68720-02020 |
Hinge Assy, Front Door, Upper LH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 68720-02020 |
Hinge Assy, Front Door, Upper LH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 68720-02020 |
Hinge Assy, Front Door, Upper LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 68720-02020 |
Hinge Assy, Front Door, Upper LH
2017-08 → —
|
USK6# HTWC | — | |
| 68730 — Hinge Assy, Front Door, Lower RH | ||||
| 68730-AC010 |
Hinge Assy, Front Door, Lower RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 68730-AC010 |
Hinge Assy, Front Door, Lower RH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 68730-AC010 |
Hinge Assy, Front Door, Lower RH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 68730-AC010 |
Hinge Assy, Front Door, Lower RH
2017-08 → —
|
USK6# HTWC | — | |
| 68730-AC010 |
Hinge Assy, Front Door, Lower RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 68740 — Hinge Assy, Front Door, Lower LH | ||||
| 68740-AC010 |
Hinge Assy, Front Door, Lower LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 68740-AC010 |
Hinge Assy, Front Door, Lower LH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 68740-AC010 |
Hinge Assy, Front Door, Lower LH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 68740-AC010 |
Hinge Assy, Front Door, Lower LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 68740-AC010 |
Hinge Assy, Front Door, Lower LH
2017-08 → —
|
USK6# HTWC | — | |
| 69801 — Regulator Sub-assy, Front Door Window, RH | ||||
| 69801-0C030 |
Regulator Sub-assy, Front Door Window, RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 69801-0C030 |
Regulator Sub-assy, Front Door Window, RH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 69801-0C030 |
Regulator Sub-assy, Front Door Window, RH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 69801-0C030 |
Regulator Sub-assy, Front Door Window, RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 69801-0C030 |
Regulator Sub-assy, Front Door Window, RH
2017-08 → —
|
USK6# HTWC | — | |
| 69802 — Regulator Sub-assy, Front Door Window, LH | ||||
| 69802-0C030 |
Regulator Sub-assy, Front Door Window, LH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 69802-0C030 |
Regulator Sub-assy, Front Door Window, LH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 69802-0C030 |
Regulator Sub-assy, Front Door Window, LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 69802-0C030 |
Regulator Sub-assy, Front Door Window, LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 69802-0C030 |
Regulator Sub-assy, Front Door Window, LH
2017-08 → —
|
USK6# HTWC | — | |
| 85701A — Motor Sub-assy, Power Window Regulator, RH | ||||
| 85701-0C010 |
Motor Sub-assy, Power Window Regulator, RH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 85701-0C010 |
Motor Sub-assy, Power Window Regulator, RH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 85701-0C010 |
Motor Sub-assy, Power Window Regulator, RH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 85701-0C010 |
Motor Sub-assy, Power Window Regulator, RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 85701-0C010 |
Motor Sub-assy, Power Window Regulator, RH
2017-08 → —
|
USK6# HTWC | — | |
| 85702B — Motor Sub-assy, Power Window Regulator, LH | ||||
| 85702-06010 |
Motor Sub-assy, Power Window Regulator, LH
2007-11 → 2009-04
ended
|
UCK6# | — | |
| 85702-06010 |
Motor Sub-assy, Power Window Regulator, LH
2007-11 → 2012-08
ended
|
UPK6# | — | |
| 85702-06010 |
Motor Sub-assy, Power Window Regulator, LH
2007-11 → 2017-08
ended
|
USK6# | — | |
| 85702-06010 |
Motor Sub-assy, Power Window Regulator, LH
2017-08 → —
|
USK6# HTWC | — | |
| 85702-06010 |
Motor Sub-assy, Power Window Regulator, LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 85710D — Motor Assy, Power Window Regulator, RH | ||||
| 85710-0C100 |
Motor Assy, Power Window Regulator, RH
2007-11 → 2007-12
ended
|
UCK6#,USK6# | — | |
| 85710-0C101 |
Motor Assy, Power Window Regulator, RH
2008-01 → 2009-04
ended
|
UCK6# | — | |
| 85710-0C101 |
Motor Assy, Power Window Regulator, RH
2008-01 → 2012-08
ended
|
UPK6# | — | |
| 85710-0C101 |
Motor Assy, Power Window Regulator, RH
2008-01 → 2017-08
ended
|
USK6# | — | |
| 85710-0C101 |
Motor Assy, Power Window Regulator, RH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 85710-0C101 |
Motor Assy, Power Window Regulator, RH
2017-08 → —
|
USK6# HTWC | — | |
| 85720C — Motor Assy, Power Window Regulator, LH | ||||
| 85720-0C030 |
Motor Assy, Power Window Regulator, LH
2007-11 → 2007-12
ended
|
UCK6#,USK6# | — | |
| 85720-0C031 |
Motor Assy, Power Window Regulator, LH
2008-01 → 2009-04
ended
|
UCK6# | — | |
| 85720-0C031 |
Motor Assy, Power Window Regulator, LH
2008-01 → 2012-08
ended
|
UPK6# | — | |
| 85720-0C031 |
Motor Assy, Power Window Regulator, LH
2008-01 → 2017-08
ended
|
USK6# | — | |
| 85720-0C031 |
Motor Assy, Power Window Regulator, LH
2017-08 → 2017-09
ended
|
USK65 HTWCF | — | |
| 85720-0C031 |
Motor Assy, Power Window Regulator, LH
2017-08 → —
|
USK6# HTWC | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
