Toyota Ractis
2010-11 → 2016-07 · chassis NCP12#,NSP12# · catalogue 114130 · Japan
Supported model
Data version 2017-01
Seat Belt & Child Restraint Seat
33 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 58237B | Bracket, Front Seat |
| 73119 | Plate, Seat Belt Webbing Clip |
| 73135A | Cover, Shoulder Belt Anchor, RH |
| 73139A | Cover, Seat Belt Anchor |
| 73143 | Seal, Seat Belt Hole |
| 73160B | Belt Assy, Wheel Chair Front Center Seat, RH |
| 73190 | Bracket Assy, Seat Belt Inner Anchor, LH |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73233 | Cover, Lap Belt Outer Anchor |
| 73233C | Cover, Lap Belt Outer Anchor, LH |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73310 | Belt Assy, Rear Seat 3 Point Type, RH |
| 73330 | Belt Assy, Rear Seat Lap Type, RH |
| 73330G | Belt Assy, RR Seat Lap Type |
| 73340B | Belt Assy, Seat Lap Type, NO.2 |
| 73360C | Belt Assy, Rear NO.1 Seat, Outer RH |
| 73370A | Belt Assy, Wheel Chair Rear Seat, Outer LH |
| 73370C | Belt Assy, Rear NO.1 Seat, Outer LH |
| 73371A | Hanger Rear Seat Shoulder Belt |
| 73380A | Belt Assy, Rear Seat, Inner |
| 73380J | Belt Assy, Wheel Chair NO.1 Seat, Inner |
| 73470B | Belt Assy, Rear Seat Inner W/Center, RH |
| 73480 | Belt Assy, Rear Seat Inner W/Center, LH |
| 73510A | Belt Assy, Rear NO.2 Seat, 3 Point Type |
| 73560B | Belt Assy, Wheel Chair Rear NO.2 Seat, Outer |
| 73580 | Belt Assy, Rear NO.2 Seat, Inner RH |
| 73580C | Belt Assy, Wheel Chair NO.2 Seat, Inner |
| 73620 | Retractor Assy, Wheel Chair NO.2 Lap Belt, LH |
| C6550 | Belt Assy, Wheel Chair Set, NO.1 |
| C6560 | Belt Assy, Wheel Chair Set, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
