Toyota Prius A(ALPHA)
2011-04 → present · chassis ZVW4# · catalogue 225110 · Japan
Supported model
Data version 2017-12
Rear Seat & Seat Track
107 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 71017 | Frame Sub-assy, Rear Seatback, RH |
| 71018 | Frame Sub-assy, Rear Seatback, LH |
| 71334A | Stopper, Rear Seat Leg |
| 71349C | Cover, Rear Seatback Hinge |
| 71349E | Cover, Rear Seatback Hinge |
| 71480E | Clip, Rear Seatback, RH |
| 71485A | Cover, Rear Seat Hinge, NO.2 RH |
| 71485C | Cover, Rear Seat Hinge, RH |
| 71486D | Cover, Rear Seat Hinge, RH |
| 71486E | Cover, Rear Seat Hinge, NO.2 RH |
| 71611A | Pad, Rear Seat Cushion, RH |
| 71612A | Pad, Rear Seat Cushion, LH |
| 71629A | Cover, Rear Seat Cushion Hinge, RH |
| 71639 | Cover, Rear Seat Cushion Hinge, LH |
| 71651S | Pad, Rear Seatback, RH(FOR SEPARATE TYPE) |
| 71652S | Pad, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71691E | Cover, Rear Seat Cushion Hinge, NO.1 |
| 71701B | Board Sub-assy, Rear Seatback, RH |
| 71702B | Board Sub-assy, Rear Seatback, LH |
| 71769A | Clip, Rear Seatback Board |
| 71811J | Cover, Reclining Adjuster, RH |
| 71812E | Cover, Reclining Adjuster, LH |
| 71812J | Clip, Rear Seat Cover |
| 71825B | Moulding, Rear Seat Cushion, RH |
| 71826B | Moulding, Rear Seat Cushion, LH |
| 71828B | Moulding, Rear Seat Cushion, Rear RH |
| 71829B | Moulding, Rear Seat Cushion, Rear LH |
| 71833A | Cover, Rear Seat Reclining, NO.1 RH |
| 71833C | Cover, Rear Seat Reclining, NO.2 RH |
| 71833E | Cover, Rear Seat Reclining, NO.3 RH |
| 71834A | Cover, Rear Seat Reclining, NO.1 LH |
| 71834B | Cover, Rear Seat Reclining, NO.2 LH |
| 71834C | Cover, Rear Seat Reclining, NO.3 LH |
| 71843A | Cover, Rear Seat Reclining, NO.2 RH |
| 71844A | Cover, Rear Seat Reclining, NO.2 LH |
| 71848C | Cap, Seat Adjuster Cover, RH |
| 71849A | Cap, Seat Adjuster Cover, LH |
| 71875C | Cover, Reclining Adjuster Inside, RH |
| 71875E | Cover, Reclining Adjuster Inside, RH |
| 71876B | Cover, Reclining Adjuster Inside, LH |
| 71876E | Cover, Reclining Adjuster Inside, LH |
| 71881 | Board, Rear Seatback, RH |
| 71882A | Board, Rear Seatback, LH |
| 71931B | Support Assy, Rear NO.1 Seat Headrest |
| 71931E | Support Assy, Rear NO.3 Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71940E | Headrest Assy, NO.2 Seat |
| 71960B | Headrest Assy, Rear Seat, Center |
| 72123C | Cover, Seat Track Bracket, Outer Front RH |
| 72124C | Cover, Seat Track Bracket, Outer Front LH |
| 72127D | Cover, Seat Track Bracket, Front, RH |
| 72127G | Cover, Seat Track Bracket, Inner Front RH |
| 72128C | Cover, Seat Track Bracket, Front, LH |
| 72128G | Cover, Seat Track Bracket, Inner Front LH |
| 72157B | Cover, Rear Seat Track Bracket, Inner RH |
| 72158A | Cover, Rear Seat Track Bracket, Inner LH |
| 72159H | Cover, Rear Seat Track Bracket |
| 72173A | Handle, Rear Seat Track Adjusting, RH |
| 72173B | Handle, Rear Seat Track Adjusting, LH |
| 72210F | Cable Assy, Seat Track Control |
| 72525C | Handle, Reclining Adjuster Release, NO.1 RH |
| 72526B | Handle, Reclining Adjuster Release, NO.1 LH |
| 72551E | Cover, Reclining Hinge, RH |
| 72552E | Cover, Reclining Hinge, LH |
| 72573B | Lever, Reclining Control, RH |
| 72574A | Lever, Reclining Control, LH |
| 72590B | Cable Assy, Reclining Remote Control |
| 72590C | Cable Assy, Reclining Remote Control |
| 72597B | Bezel, Reclining Remote Control Lever, NO.1 |
| 72598C | Bezel, Reclining Remote Control, LH |
| 72615A | Cover, Rear Seatback Lock Striker, RH |
| 72616A | Cover, Rear Seatback Lock Striker, LH |
| 72663 | Lever, Rear Seat Lock Control, NO.1 |
| 72690 | Lever Assy, Seat Cushion Lock Release |
| 72749 | Spacer, Rear Seat Reclining |
| 72779 | Guide, Rear Seat Hinge Pawl |
| 72779A | Guide, Rear Seat Hinge Pawl |
| 72830 | Armrest Assy, Rear Seat, Center |
| 72831B | Plate, Rear Seat Center Armrest, NO.1 |
| 72831C | Plate, Rear Seat Center Armrest, NO.2 |
| 72868 | Cover, Center Armrest Hinge, RH |
| 72868B | Cover, Center Armrest Hinge |
| 72921 | Strap, 3RD Seat |
| 72927B | Cover, Rear Seat Cushion Under |
| 72995 | Cover, Rear Seat Cushion, RH |
| 74865A | Cover, Center Protector |
| 79011 | Cover Sub-assy, NO.1 Seat Cushion, RH |
| 79012 | Cover Sub-assy, NO.1 Seat Cushion, LH |
| 79013 | Cover Sub-assy, NO.1 Seatback, RH |
| 79014 | Cover Sub-assy, NO.1 Seatback, LH |
| 79021 | Cover Sub-assy, NO.2 Seat Cushion, RH |
| 79022 | Cover Sub-assy, NO.2 Seat Cushion, LH |
| 79023 | Cover Sub-assy, NO.2 Seatback, RH |
| 79024 | Cover Sub-assy, NO.2 Seatback, LH |
| 79101B | Frame Sub-assy, NO.1 Seat Cushion, RH |
| 79102 | Frame Sub-assy, NO.1 Seat Cushion, LH |
| 79201B | Frame Sub-assy, NO.2 Seat Cushion, RH |
| 79202 | Frame Sub-assy, NO.2 Seat Cushion, LH |
| 79203A | Frame Sub-assy, NO.2 Seatback, RH |
| 79204A | Frame Sub-assy, NO.2 Seatback, LH |
| 79205 | Leg Sub-assy, NO.2 Seat |
| 79235D | Pad, NO.2 Seat Cushion, RH |
| 79245C | Pad, NO.2 Seat Cushion, LH |
| 79275C | Pad, NO.2 Seatback, RH |
| 79285 | Pad, NO.2 Seatback, LH |
| 79956B | Cover, Rear Seat Leg Side, RH |
| 79956C | Cover, Rear Seat Leg Side, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
