Toyota Crown/Crown Majesta
1991-10 → 1995-08 · chassis JZS14#,LS141,UZS14#,GS141 · catalogue 331180 · Japan
Discontinued model
Data version 1996-03
Front Seat & Seat Track
97 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71328B | Washer, Front Seatback Pocket Setting, RH |
| 71328C | Washer, Front Seatback Pocket Setting, LH |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71521A | Pad,Front Seat Cushion Silencer |
| 71521B | Pad,Front Seat Cushion Silencer |
| 71522A | Pad, Front Seat Cushion Silencer, B |
| 71522B | Pad, Front Seat Cushion Silencer, B |
| 71523A | Pad, Front Seat Cushion Silencer, C |
| 71524 | Pad, Front Seat Cushion Silencer, D |
| 71524A | Pad, Front Seat Cushion Silencer, D |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71610S | Spring Assy, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71620S | Spring Assy, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71630S | Spring Assy, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71640S | Spring Assy, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71705 | Board Sub-assy, Front Seatback, RH |
| 71706 | Board Sub-assy, Front Seatback, LH |
| 71711 | Leather, For Seat, A RH |
| 71711A | Leather, For Seat, A LH |
| 71712 | Leather, For Seat, B RH |
| 71712A | Leather, For Seat, B LH |
| 71811C | Cover, Reclining Adjuster, RH |
| 71812C | Cover, Reclining Adjuster, LH |
| 71831B | Cover, Front Seat Hinge, RH |
| 71831D | Cover, Front Seat Hinge, RH |
| 71832B | Cover, Front Seat Hinge, LH |
| 71832D | Cover, Front Seat Hinge, LH |
| 71848A | Cap, Seat Adjuster Cover, RH |
| 71861 | Shield, Front Seat Cushion, Inner RH |
| 71862 | Shield, Front Seat Cushion, Inner LH |
| 71867A | Shield, Front Seat Cushion, Inner NO.1 RH |
| 71868A | Shield, Front Seat Cushion, Inner NO.1 LH |
| 71873 | Shield, Front Seat Cushion, Lower RH |
| 71874 | Shield, Front Seat Cushion, Lower LH |
| 71875A | Cover, Reclining Adjuster Inside, RH |
| 71876 | Cover, Reclining Adjuster Inside, LH |
| 71893A | Shield, Power Adjuster, Front RH |
| 71894A | Shield, Power Adjuster, Front LH |
| 71910A | Headrest Assy, Front Seat |
| 71920A | Headrest Assy, Front Seat, LH |
| 71925A | Cover, Front Seat Headrest Stay,RH |
| 71926 | Cover, Front Seat Headrest Stay,LH |
| 71931 | Support, Front Seat Headrest |
| 71937 | Handle, Front Seat Headrest Regulator |
| 72043B | Lever Sub-assy, Seat Lifter, RH |
| 72110 | Regulator Assy, Power Seat, RH |
| 72110A | Track Assy, Front Seat, Outer RH |
| 72120 | Track Assy, Front Seat, Outer LH |
| 72120A | Regulator Assy, Power Seat, LH |
| 72123A | Cover, Seat Track Bracket, Outer Front RH |
| 72124 | Cover, Seat Track Bracket, Outer Front LH |
| 72127A | Cover, Seat Track Bracket, Inner Front RH |
| 72128A | Cover, Seat Track Bracket, Inner Front LH |
| 72130A | Track Assy, Front Seat, Inner RH |
| 72137B | Cover, Seat Track, RH |
| 72138B | Cover, Seat Track, LH |
| 72140A | Track Assy, Front Seat,Inner LH |
| 72157A | Cover, Seat Track Bracket, Inner RH |
| 72158 | Cover, Seat Track Bracket, Inner LH |
| 72205A | Housing Sub-assy, Power Seat, NO.1 |
| 72205E | Housing Sub-assy, Power Seat, NO.1 |
| 72206 | Housing Sub-assy, Power Seat, NO.2 |
| 72206C | Housing Sub-assy, Power Seat, NO.2 |
| 72301A | Wire Sub-assy, Seat Track Equalizing, RH |
| 72301D | Wire Sub-assy, Seat Track Equalizing, LH |
| 72310A | Adjuster Assy, Front Seat Vertical |
| 72380 | Cable Assy, Seat Adjuster Control, NO.2 |
| 72405 | Housing Sub-assy, Front Seat Vertical |
| 72405A | Housing Sub-assy, Front Seat Vertical |
| 72459 | Cap, Vertical Seat Adjuster Knob |
| 72480 | Adjuster Assy, Front Seat Vertical, NO.2 RH |
| 72501D | Pipe Sub-assy, Reclining Connecting, RH |
| 72501E | Pipe Sub-assy, Reclining Connecting, LH |
| 72510D | Adjuster Assy, Reclining Seat, Outer RH |
| 72520 | Adjuster Assy, Reclining Seatback, LH |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72526 | Handle, Reclining Adjuster Release, LH |
| 72530A | Adjuster Assy, Reclining Seat, Inner RH |
| 72540A | Adjuster Assy, Reclining Seat, Inner LH |
| 72578 | Pin, Front Seatback Stopper |
| 72750D | Adjuster Assy, Lumbar Support, RH |
| 72791 | Lever, Lumbar Support |
| 72791A | Ring, Shaft Snap(FOR LUMBER SUPPORT LEVER) |
| 74617D | Plug, Assist Grip |
| 74620A | Grip Assy, Assist, Rear |
| 74671C | Support, Assist Grip |
| 79144 | Stopper, NO.1 Seatback, Front |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
