Toyota Dyna/Toyoace
2011-07 → present · chassis BZU600,TRC600,TRU600,XZC6##,XZU6## · catalogue 751190 · Japan
Supported model
Data version 2019-05
Fuel Filter
23 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 23104A | Valve Sub-assy |
| 23264D | Bracket, Fuel Filter |
| 23300 | Filter Assy, Fuel |
| 23300D | Filter Assy, Fuel(FOR DIESEL) |
| 23301 | Body Sub-assy, Fuel Filter |
| 23304A | Element Set, Fuel Filter |
| 23310 | Body, Fuel Filter, Upper |
| 23328 | Gasket(FOR FUEL FILTER) |
| 23330 | Prefilter Assy, Fuel |
| 23330A | Gasket |
| 23352 | Plug, Bleeder |
| 23355 | Element, Prefilter |
| 23380 | Cap Assy, Fuel Filter |
| 23382 | Case, Fuel Filter |
| 23383 | Union, Fuel Filter |
| 23386 | Gasket, Fuel Filter Case |
| 23388 | Plug, Fuel Filter Drain |
| 23388A | Plug, Fuel Filter Drain |
| 23390 | Element Assy, Fuel Filter |
| 23921 | Support, Fuel Filter |
| 23921B | Bracket(FOR FUEL FILTER) |
| 23925 | Stay, Fuel Filter Support |
| 23941 | Protector, Fuel Filter, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
