Toyota Dyna/Toyoace

2011-07 → present · chassis XZC710,XZU7## · catalogue 771140 · Japan

Supported model Data version 2022-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Power Take-off Lever & Link

19 part groups · 19 illustrations

Illustrations

Figure 361633B 361633B 2011-07 → 2017-05 Figure 361633B 361633B 2011-07 → 2017-05 Figure 361633B 361633B 2017-05 → 2019-05 Figure 361633B 361633B 2017-05 → 2019-05 Figure 361633B 361633B 2019-05 → 2021-03 Figure 361633B 361633B 2019-05 → — Figure 361633B 361633B 2021-03 → — Figure 361633B 361633B 2021-03 → — Figure 361636C 361636C 2011-07 → 2017-05 Figure 361636C 361636C 2017-05 → 2019-05 Figure 361635B 361635B 2011-07 → 2017-05 Figure 361824B 361824B 2013-05 → 2017-05 Figure 361824B 361824B 2017-05 → 2019-05 Figure 361824B 361824B 2019-05 → 2021-03 Figure 361824B 361824B 2021-03 → — Figure 362161B 362161B 2017-05 → 2019-05 Figure 362161B 362161B 2019-05 → 2021-03 Figure 362161B 362161B 2019-05 → — Figure 362161B 362161B 2021-03 → —

Part groups

PNCDescription
33829J Clamp, Transmission Control Cable
38901D Lever Sub-assy, Valve Control
38901H Knob, Valve Control Lever
38901J Lever Sub-assy, Valve Control
38902B Bracket Sub-assy, Valve Control Lever
38902C Bush (FOR VALVE CONTROL LEVER)
38907E Stay Sub-assy, Power Teke-off Control
38914A Pipe, Valve Control Lever
38914B Pipe, Valve Control Lever, NO.2
38920A Lever Assy, Power Take-off Control, NO.1
38927 Cover, Valve Control Lever
38930A Cable Assy, Push Pull
38962 Bracket, Cable Clamp, NO.2
38962A Bracket, Cable Clamp, NO.7
38963 Bracket, Cable Clamp, NO.3
38976C Clamp, Push Pull Cable
38982 Clamp, Push Pull Cable, NO.1
38987 Clamp, Cable Push Pull
38987A Clamp, Push Pull Cable
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
