Toyota Dyna/Toyoace

2011-07 → present · chassis XZC710,XZU7## · catalogue 771140 · Japan

Supported model Data version 2022-07

Front Axle Arm & Steering Knuckle

37 part groups · 4 illustrations

PNC	Description
04431	Pin Kit, Steering Knuckle King
43111	I Beam, Front Axle
43112	Pin, King Pin Lock
43132A	Bolt, Round Hexagon (FOR STEERING KNUCKLE STOPPER BOLT)
43211	Knuckle, Steering, RH
43211D	Plug (FOR STEERING KNUCKLE)
43211Q	Seal, Oil (FOR STEERING KNUCKLE)
43212	Knuckle, Steering, LH
43231A	Bush, Bimetal Formed (FOR STEERING KNUCKLE KING PIN BUSH)
43231B	Seal, Dust OR Ring, O (FOR STEERING KNUCKLE KING PIN)
43231C	Bearing (FOR STEERING KNUCKLE KING PIN)
43231D	Shim (FOR KING PIN)
43241	Cover, Steering Kunckle Oil Seal
43310B	Ring, Set (FOR DUST COVER)
43324B	Cover, Front Upper Ball Joint Dust, RH
43324C	Cover, Front Upper Ball Joint Dust, LH
43330K	Joint Assy, Lower Ball, Front RH
43340A	Joint Assy, Lower Ball, Front LH
43350	Joint Assy, Front Upper Ball, RH
43360	Joint Assy, Front Upper Ball, LH
45543	Protector, Steering Rack Boot, RH
45543E	Protector, Steering Rack Boot,RH NO.2
45544	Protector, Steering Rack Boot, LH
45544C	Protector, Steering Rack Boot, LH NO.2
48066	Arm Sub-assy, Front Suspension, Upper RH
48067	Arm Sub-assy, Front Suspension, Upper LH
48068	Arm Sub-assy, Front Suspension, Lower NO.1 RH
48069	Arm Sub-assy, Front Suspension, Lower NO.1 LH
48195	Shim, Camber Adjust
48610D	Nut(FOR SUSPENSION UPPER ARM)
48632A	Bush, Front Suspension Upper Arm, RH
48632B	Bush, Front Suspension Upper Arm, LH
48633A	Seal, Front Suspension Upper Arm Pivot Dust, RH
48633B	Seal, Front Suspension Upper Arm Pivot Dust, LH
48655	Bush, Lower Arm, NO.2
48660C	Arm Assy, Suspension, Lower NO.2 RH
48670A	Arm Assy, Suspension, Lower NO.2 LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
