Toyota Tundra/Sequoia
2021-11 → present · chassis VXKA7#,VXKH7#,VXKH8# · catalogue 841440 · United States
Supported model
Data version 2022-06
Inside Trim Board
70 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 58440H | Cover Assy, Battery Service Hole, RH |
| 58440J | Cover Assy, Battery Service Hole, LH |
| 62111C | Board, Cowl Side Trim, RH |
| 62112A | Trim Sub-assy, Cowl Side, LH |
| 62117B | Clip, NO.1(FOR COWL SIDE TRIM) |
| 62117C | Clip, NO.2(FOR COWL SIDE TRIM) |
| 62170A | Airbag Assy, Curtain Shield, RH |
| 62170B | Bolt, W/Washer |
| 62180A | Airbag Assy, Curtain Shield, LH |
| 62211U | Garnish Assy, Front Pillar, RH |
| 62212B | Garnish Assy, Front Pillar, LH |
| 62217G | Clip, Front Pillar Garnish |
| 62311B | Weatherstrip, Front Door Opening Trim, RH |
| 62312B | Weatherstrip, Front Door Opening Trim, LH |
| 62331C | Weatherstrip, Rear Door Opening Trim, RH |
| 62332C | Weatherstrip, Rear Door Opening Trim, LH |
| 62401A | Clip (FOR CENTER PILLAR GARNISH PANEL, UPPER) |
| 62411 | Garnish, Center Pillar, RH |
| 62411H | Clip |
| 62412 | Garnish, Center Pillar, LH |
| 62413A | Garnish, Center Pillar, Lower RH |
| 62413C | Clip (FOR CENTER LOWER GARNISH) |
| 62414A | Garnish, Center Pillar, Lower LH |
| 62430 | Garnish Assy, Roof Side Rail, RH |
| 62440 | Garnish Assy, Roof Side Rail, LH |
| 62468A | Clip (FOR CENTER PILLAR REAR GARNISH) |
| 62471G | Clip, Roof Side Inner Garnish |
| 62489A | Clip, Roof Side Inner Garnish |
| 62489B | Clip, Roof Side Inner Garnish |
| 62510H | Clip(FOR QUARTER TRIM FRONT PANEL) |
| 62510P | Panel Assy, Quarter Trim, Front RH |
| 62520P | Panel Assy, Quarter Trim, Front LH |
| 62521B | Cover, Quarter Trim, RH |
| 62522A | Cover, Quarter Trim, LH |
| 62530 | Panel Assy, Quarter Trim, Lower RH |
| 62530B | Clip, Quarter Trim NO.1 |
| 62534D | Bracket, Quarter Trim, NO.1, LH |
| 62540 | Panel Assy, Quarter Trim, Lower LH |
| 62550E | Trim Assy, Side NO.3, RH |
| 62560B | Trim Assy, Side, NO.3 LH |
| 62570C | Trim Assy, Side NO.4 |
| 62580D | Trim Assy, Side NO.4 LH |
| 62597D | Clip |
| 62621E | Clip |
| 62627B | Cover, Quarter Trim |
| 62638B | Clip |
| 62666 | Cover, Quarter Trim, RH |
| 62667 | Cover, Quarter Trim, LH |
| 64141F | Sheet, Room Partition Panel Silencer, NO.1 RH |
| 64141G | Sheet, Room Partition Panel Silencer, NO.1 LH |
| 64267B | Hook, Package Holder Net |
| 64367B | Strap, Package Tray Trim |
| 64424 | Separator, Luggage Room Box |
| 64429H | Tray, Luggage Compartment Side |
| 64429J | Tray, Luggage Compartment Side |
| 64726D | Clip, Luggage Trim, Rear |
| 64745H | Holder, Deck Side Trim Cup, RH |
| 64746F | Holder, Deck Side Trim Cup, LH |
| 67675D | Clip, Side Trim Board Cover |
| 67911B | Plate, Front Door Scuff, Outside, RH |
| 67912A | Plate, Front Door Scuff, Outside LH |
| 67913B | Plate, Front Door Scuff, RH |
| 67914B | Plate, Front Door Scuff, LH |
| 67915 | Plate, Rear Door Scuff, Outside RH |
| 67916 | Plate, Rear Door Scuff, Outside LH |
| 67917C | Plate, Rear Door Scuff, RH |
| 67917D | Clip, Rear Door Scuff Plate |
| 67918E | Plate, Rear Door Scuff, LH |
| 73297E | Cover, Deck Trim Side Belt Hole, RH |
| 73298D | Cover,Deck Trim Side Belt Hole, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
