Toyota Crown
1979-09 → 1983-07 · chassis RS110,MS11#,LS110 · catalogue 331240 · Europe
Discontinued model
Data version 1984-02
Front Seat & Seat Track
83 part groups · 11 illustrations
Part groups
| PNC | Description |
|---|---|
| 71071B | Cover, Front Seat Cushion(FOR BENCH TYPE) |
| 71071P | Cover, Front Seat Cushion(FOR SEMI-SEPARATE TYPE) |
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073B | Cover, Front Seatback(FOR BENCH TYPE) |
| 71073P | Cover, Front Seatback, RH(FOR SEMI-SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074P | Cover, Front Seatback, LH(FOR SEMI-SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71105 | Link Sub-assy, Front Seat Center Armrest, RH |
| 71106 | Link Sub-assy, Front Seat Center Armrest, LH |
| 71410B | Cushion Assy, Front Seat(FOR BENCH TYPE) |
| 71410P | Cushion Assy, Front Seat(FOR SEMI-SEPARATE TYPE) |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430B | Back Assy, Front Seat(FOR BENCH TYPE) |
| 71430P | Back Assy, Front Seat, RH(FOR SEMI-SEPARATE TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440P | Back Assy, Front Seat, LH(FOR SEMI-SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71511B | Pad, Front Seat Cushion(FOR BENCH TYPE) |
| 71511P | Pad, Front Seat Cushion(FOR SEMI-SEPARATE TYPE) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71513B | Pad, Front Seat Cushion, B |
| 71521 | Pad, Front Seat Cushion Silencer, A |
| 71522A | Pad, Front Seat Cushion Silencer, B |
| 71523A | Pad, Front Seat Cushion Silencer, C |
| 71524 | Pad, Front Seat Cushion Silencer, D |
| 71531 | Pad, Front Seat Cushion Corner, A |
| 71532 | Pad, Front Seat Cushion Corner, B |
| 71551B | Pad, Front Seatback(FOR BENCH TYPE) |
| 71551P | Pad, Front Seatback, RH(FOR SEMI-SEPARATE TYPE) |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552P | Pad, Front Seatback, LH(FOR SEMI-SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71554 | Pad, Front Seatback, C |
| 71565 | Pad, Front Seatback, Inside |
| 71567 | Pad, Front Seatback Safety |
| 71571 | Pad, Front Seatback Silencer, A |
| 71572 | Pad, Front Seatback Silencer, B |
| 71573 | Pad, Front Seatback Silencer, C |
| 71584 | Pad, Front Seatback Corner, D |
| 71587 | Protector, Front Seatback Edge |
| 71610B | Spring Assy, Front Seat Cushion(FOR BENCH TYPE) |
| 71610P | Spring Assy, Front Seat Cushion(FOR SEMI-SEPARATE TYPE) |
| 71610S | Spring Assy, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71620S | Spring Assy, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71630B | Spring Assy, Front Seatback(FOR BENCH TYPE) |
| 71630P | Spring Assy, Front Seatback, RH(FOR SEMI-SEPARATE TYPE) |
| 71630S | Spring Assy, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71640P | Spring Assy, Front Seatback, LH(FOR SEMI-SEPARATE TYPE) |
| 71640S | Spring Assy, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71705 | Board Sub-assy, Front Seatback, RH |
| 71706 | Board Sub-assy, Front Seatback, LH |
| 71803 | Holder Sub-assy, Front Seat Armrest |
| 71804 | Board Sub-assy, Front Seat Armrest Hole |
| 71805 | Board Sub-assy, Front Seat Armrest Holder |
| 71810 | Armrest Assy, Front Seat Center |
| 71811D | Shield, Front Seat Cushion, RH |
| 71812A | Ring, Hog, Small (FOR FRONT SEAT) |
| 71812D | Shield, Front Seat Cushion, LH |
| 71824 | Bracket, Front Seat Side, NO.1 RH |
| 71825 | Bracket, Front Seat Side, NO.1 LH |
| 71826 | Bracket, Front Seat Side, NO.2 |
| 71863 | Moulding, Front Seat Armrest Holder Board |
| 71950 | Headrest Assy, Front Seat |
| 71956A | Support, Front Seat Headrest |
| 72510 | Adjuster Assy, Reclining Seatback, RH |
| 72510A | Spring, Tension, NO.1(FOR RECLINING SEAT ADJUSTER) |
| 72519 | Knob, Reclining Seatback Adjusting Arm |
| 72520 | Adjuster Assy, Reclining Seatback, LH |
| 72537 | Cover, Reclining Hinge Outer, RH |
| 72538 | Cover, Reclining Hinge Outer, LH |
| 72707 | Lever Sub-assy, Lumber Support, RH |
| 72708 | Lever Sub-assy, Lumber Support, LH |
| 72760 | Adjuster Assy, Lumbar Support, RH |
| 72770 | Adjuster Assy, Lumbar Support, LH |
| 72773 | Plate, Lumbar Support |
| 72791 | Lever, Lumbar Support |
| 74650 | Panel Assy, Front Seatback Control |
| 74658 | Ornament, Front Seatback Control Panel |
| 74659 | Retainer, Front Seatback Control Panel |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
