Toyota Lexus LX Series
2021-12 → present · chassis FJA310,VJA310,VJH310 · catalogue 792270 · Europe
Supported model
Data version 2024-11
Instrument Panel & Glove Compartment
43 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 52161V | Piece, Instrument Panel |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55312 | Panel, Instrument, Lower |
| 55317E | Panel, Instrument Side, NO.1 |
| 55318F | Panel, Instrument Side, NO.2 |
| 55320 | Panel Assy, Instrument, Lower NO.2 |
| 55328 | Pin, Instrument Panel, NO.1 |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55374A | Bracket, Instrument Panel Lower Mounting, RH |
| 55375A | Bracket, Instrument Panel Lower Mounting, LH |
| 55400 | Pad Assy, Instrument Panel Safety |
| 55402A | Pad Sub-assy, Instrument Panel, Lower NO.1 |
| 55403H | Pad Sub-assy, Instrument Panel, Lower NO.2 |
| 55404D | Panel Sub-assy, Instrument Cluster Finish |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55408F | Panel Sub-assy, Instrument Panel Speaker, NO.1 |
| 55409F | Panel Sub-assy, Instrument Panel Speaker, NO.2 |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55414A | Panel, Instrument Cluster Finish, End |
| 55416A | Retainer, Meter Hood, NO.1 |
| 55423 | Panel, Stereo Player Finish |
| 55432D | Panel, Instrument Panel Finish, Lower NO.1 |
| 55458B | Cover, Instrument, Lwr |
| 55501A | Door Sub-assy, Glove Compartment |
| 55506F | Lock Sub-assy, Glove Compartment Door |
| 55510F | Cover Assy, Speaker Opening, NO.1 |
| 55512A | Plate, Glove Compartment |
| 55539 | Cover, Spare Switch Hole |
| 55539B | Cover, Spare Switch Hole, NO.2 |
| 55557A | Cushion, Glove Compartment Door Check |
| 55569 | Cover, Glove Compartment Door Lock |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55607 | Cover Sub-assy, Instrument Panel Under, NO.2 |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55680A | Register Assy, Instrument Panel, NO.4 |
| 55981 | Garnish, Defroster Nozzle, NO.1 |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
| 73990 | Airbag Assy, Instrument Panel, Lower NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
