Toyota Crown Comfort/Sed
1995-12 → 2018-01 · chassis GXS1#,LXS11,SXS1#,YXS1#,GBS12,TSS1# · catalogue 333110 · Japan
Discontinued model
Data version 2018-07
Side Member
76 part groups · 10 illustrations
Part groups
| PNC | Description |
|---|---|
| 53821B | Bracket, Front Fender, Rear RH |
| 53822B | Bracket, Front Fender, Rear LH |
| 57497B | Shield, Rear Floor Housing, RH |
| 57498B | Shield, Rear Floor Housing, LH |
| 61023B | Pillar Sub-assy, Front Body, Inner RH |
| 61024B | Pillar Sub-assy, Front Body, Inner LH |
| 61037A | Reinforcement Sub-assy, Center Body Pillar, RH |
| 61038A | Reinforcement Sub-assy, Center Body Pillar, LH |
| 61108A | Reinforce Sub-assy, Front Body Pillar, Lower RH |
| 61109A | Reinforce Sub-assy, Front Body Pillar, Lower LH |
| 61131 | Pillar, Front Body, Upper Outer RH |
| 61132 | Pillar, Front Body, Upper Outer LH |
| 61145B | Gusset, Front Body Pillar, Lower RH |
| 61146B | Gusset, Front Body Pillar, Lower LH |
| 61167C | Bracket, Front Body Pillar TO Cowl Top, RH |
| 61168 | Bracket, Instrument Panel TO Cowl Side, LH |
| 61182B | Bracket, Instrument Panel Side, NO.1 LH |
| 61211 | Rail, Roof Side, Outer RH |
| 61212 | Rail, Roof Side, Outer LH |
| 61216A | Rail, Roof Side, Outer Rear LH |
| 61231 | Rail, Roof Side, Inner RH |
| 61232 | Rail, Roof Side, Inner LH |
| 61232A | Rail, Roof Side, Inner LH |
| 61235B | Bracket, Assist Grip |
| 61236C | Bracket, Assist Grip |
| 61238D | Bracket, Assist Grip, NO.2 LH |
| 61245 | Reinforcement, Roof Side Rail, Outer RH |
| 61246 | Reinforcement, Roof Side Rail, Outer LH |
| 61261 | Channel, Roof Drip, RH |
| 61262 | Channel, Roof Drip, LH |
| 61311B | Pillar, Center Body, Outer RH |
| 61312B | Pillar, Center Body, Outer LH |
| 61341C | Pillar, Center Body, Inner Upper RH |
| 61342C | Pillar, Center Body, Inner Upper LH |
| 61343A | Pillar, Center Body, Inner RH |
| 61344A | Pillar, Center Body, Inner LH |
| 61403C | Reinforce Sub-assy, Rocker, Outer RH |
| 61404E | Reinforce Sub-assy, Rocker, Outer LH |
| 61411 | Panel, Rocker, Outer RH |
| 61412 | Panel, Rocker, Outer LH |
| 61413C | Reinforcement, Rocker Panel, NO.2 RH |
| 61414C | Reinforcement, Rocker Panel, NO.2 LH |
| 61432 | Panel, Rocker, Outer Rear LH |
| 61434A | Reinforcement, Rocker Panel, Outer LH |
| 61601B | Panel Sub-assy, Quarter, RH |
| 61602C | Panel Sub-assy, Quarter, LH |
| 61607E | Panel, Quarter Wheel House, Inner RH |
| 61608D | Panel, Quarter Wheel House, Inner LH |
| 61609B | Brace Sub-assy, Quarter Panel |
| 61621C | Trough, Luggage Compartment Opening, RH |
| 61622C | Trough, Luggage Compartment Opening, LH |
| 61625G | Extension, Quarter Panel, Rear RH |
| 61626G | Extension, Quarter Panel, Rear LH |
| 61627E | Extension, Quarter Panel, Rear Lower RH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61641C | Gusset, Quarter Wheel House, Front RH |
| 61642C | Gusset, Quarter Wheel House, Front LH |
| 61646B | Gusset, Quarter Wheel House, Rear LH |
| 61681D | Plate, Quarter Panel, Lower NO.1 |
| 61711 | Panel, Roof Side, Outer RH |
| 61712 | Panel, Roof Side, Outer LH |
| 61731B | Panel, Roof Side, Inner RH |
| 61732B | Panel, Roof Side, Inner LH |
| 61786F | Bracket, Rear Bumper Side, RH |
| 61787E | Bracket, Rear Bumper Side, LH |
| 61817B | Cover, Roof Side, Inner Lower RH |
| 61825A | Plate, Noise Control, NO.2 |
| 61826A | Plate, Noise Control, NO.3 |
| 62465C | Pad, Quarter Lock Pillar, RH |
| 62466B | Pad, Quarter Lock Pillar, LH |
| 62589E | Pad, Quarter Pillar |
| 63171A | Bracket, Room Lamp |
| 67811B | Pad, Side Panel Silencer |
| 75941A | Stripe, Center Pillar, RH |
| 75942B | Stripe, Center Pillar, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
