Toyota Cami
1999-05 → 2005-12 · chassis J100E,J102E,J122E · catalogue 661130 · Japan
Discontinued model
Data version 2006-07
Seat & Seat Track
79 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71075S | Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE) |
| 71076S | Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71077S | Cover, Rear Seatback, RH (FOR SEPARATE TYPE) |
| 71078S | Cover, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71121 | Bracket, Front Seat Cushion, RH |
| 71122 | Bracket, Front Seat Cushion, LH |
| 71170A | Holder Assy, Front Seat Armrest, RH |
| 71301D | Hinge Sub-assy, Rear Seat, RH |
| 71302D | Hinge Sub-assy, Rear Seat, LH |
| 71306D | Bracket Sub-assy, Front Seat Set |
| 71345 | Hinge, Rear Seatback |
| 71349B | Cover, Rear Seatback Stay, RH |
| 71369B | Cover, Rear Seatback Stay, LH |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71460S | Cushion Assy, Rear Seat, RH(FOR SEPARATE TYPE) |
| 71470S | Cushion Assy, Rear Seat, LH (FOR SEPARATE TYPE) |
| 71480S | Back Assy, Rear Seat, RH (FOR SEPARATE TYPE) |
| 71490S | Back Assy, Rear Seat, LH (FOR SEPARATE TYPE) |
| 71753 | Tray, Front Seat Under |
| 71811D | Shield, Front Seat Cushion, RH |
| 71812 | Clip (FOR FRONT SEAT CUSHION COVER) |
| 71812D | Shield, Front Seat Cushion, LH |
| 71812H | Ring, Hog, Small (FOR REAR SEAT) |
| 71833A | Cover, Rear Seat Reclining, NO.1 RH |
| 71834A | Cover, Rear Seat Reclining, NO.1 LH |
| 71875A | Cover, Reclining Adjuster Inside, RH |
| 71876 | Cover, Reclining Adjuster Inside, LH |
| 71881 | Board, Rear Seatback, RH |
| 71881B | Clip, Rear Seatback Board |
| 71882A | Board, Rear Seatback, LH |
| 71910A | Headrest Assy, Front Seat |
| 71931 | Support, Front Seat Headrest |
| 71931A | Support, Rear Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 72011 | Adjuster Sub-assy, Front Seat, Outer RH |
| 72012 | Adjuster Sub-assy, Front Seat, Outer LH |
| 72021 | Adjuster Sub-assy, Front Seat, Inner RH |
| 72022 | Adjuster Sub-assy, Front Seat, Inner LH |
| 72065A | Hook Sub-assy,Rear Seat Cushion Lock,RH |
| 72066A | Hook Sub-assy,Rear Seat Cushion Lock,LH |
| 72125A | Cover, Seat Track, Upper Rear |
| 72125D | Cover, Seat Track, Upper Rear NO.2 |
| 72137 | Cover, Seat Track, Outer RH |
| 72137B | Cover, Seat Track, RH |
| 72137K | Cover, Front Seat Track, RH Rear Inner |
| 72137L | Cover, Front Seat Track, RH Front Inner |
| 72138 | Cover, Seat Track, Outer LH |
| 72138B | Cover, Seat Track, LH |
| 72211 | Handle, Seat Track Adjusting |
| 72510 | Adjuster Assy, Reclining Seatback, RH |
| 72520D | Adjuster Assy, Reclining Seat, Outer LH |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72526A | Handle, Reclining Adjuster Release, LH |
| 72635A | Bolt,Rear Seat Lock |
| 72637A | Handle, Rear Seat Lock |
| 72660A | Support Assy, Rear Seat Cushion |
| 72660D | Support Assy, Rear Seat Cushion |
| 72665 | Cover, Rear Seatback Lock, RH |
| 72666 | Cover, Rear Seatback Lock, LH |
| 72681 | Hook, Rear Seatback Lock, Lower |
| 72694 | Cover, Rear Seat Cushion Lock |
| 72697 | Spring, Rear Seat Lock Lever, RH |
| 72698A | Spring,Rear Seat Lock Lever,LH |
| 72724 | Pin, Rear Seat Reclining Control Lever |
| 72725 | Hook, Front Seatback |
| 72730A | Adjuster Assy, Rear Seat Reclining, RH |
| 72740A | Adjuster Assy, Rear Seat Reclining, LH |
| 72810A | Armrest Assy, Seat, RH |
| 73705 | Bracket Sub-assy, Child Restraint Seat Anchor, RH |
| 73910A | Airbag Assy, Front Seat, RH |
| 73920A | Airbag Assy, Front Seat, LH |
| 73949 | Cap |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
