Toyota Porte/Spade
2012-07 → 2020-12 · chassis NCP14#,NSP14# · catalogue 123120 · Japan
Supported model
Data version 2022-07
Rear Seat & Seat Track
61 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 71015 | Frame Sub-assy, Rear Seat Cushion |
| 71015A | Frame Sub-assy, Rear Seat Cushion, RH |
| 71016A | Frame Sub-assy, Rear Seat Cushion, LH |
| 71017 | Frame Sub-assy, Rear Seatback, RH |
| 71017A | Frame Sub-assy, Rear Seatback |
| 71018 | Frame Sub-assy, Rear Seatback, LH |
| 71075B | Cover, Rear Seat Cushion (FOR BENCH TYPE) |
| 71075S | Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE) |
| 71076S | Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71077B | Cover, Rear Seatback (FOR BENCH TYPE) |
| 71077S | Cover, Rear Seatback, RH (FOR SEPARATE TYPE) |
| 71078S | Cover, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71303C | Hinge Sub-assy, Rear Seatback, RH |
| 71309A | Bracket Sub-assy, Rear Seatback Holder |
| 71345 | Hinge, Rear Seatback |
| 71405A | Striker Sub-assy, Rear Seat Lock, RH |
| 71406 | Striker Sub-assy, Rear Seat Lock, LH |
| 71485C | Cover, Rear Seat Hinge, RH |
| 71486C | Cover, Rear Seat Hinge, LH |
| 71611 | Pad, Rear Seat Cushion |
| 71611A | Pad, Rear Seat Cushion, RH |
| 71612A | Pad, Rear Seat Cushion, LH |
| 71651B | Pad, Rear Seatback(FOR BENCH TYPE) |
| 71651S | Pad, Rear Seatback, RH(FOR SEPARATE TYPE) |
| 71652S | Pad, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71695C | Protector, Rear Seat, NO.1 |
| 71696A | Protector, Rear Seat, NO.2 LH |
| 71931A | Support, Rear Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71951A | Cover, Rear Seat Headrest |
| 71951B | Cover, Rear Seat Headrest, Center |
| 71960B | Headrest Assy, Rear Seat, Center |
| 72065A | Hook Sub-assy,Rear Seat Cushion Lock,RH |
| 72066A | Hook Sub-assy,Rear Seat Cushion Lock,LH |
| 72137D | Cover, Rear Seat Track, RH |
| 72137S | Cover, Seat Track Bracket, Outer Rear RH |
| 72138A | Cover, Rear Seat Track, LH |
| 72138M | Cover, Seat Track Bracket, Outer Rear LH |
| 72157B | Cover, Rear Seat Track Bracket, Inner RH |
| 72157D | Cover, Seat Track Bracker, Inner RH |
| 72158A | Cover, Rear Seat Track Bracket, Inner LH |
| 72158B | Cover, Seat Track Bracket, Inner LH |
| 72601A | Striker Sub-assy, Rear Seatback Look, RH |
| 72601B | Striker Sub-assy, Rear Seatback Lock |
| 72602A | Striker Sub-assy, Rear Seatback Lock, LH |
| 72630C | Lock Assy, Rear Seatback, RH |
| 72640A | Lock Assy, Rear Seatback, LH |
| 72646 | Grommet, Rear Seatback Stop Button |
| 72661C | Button, Rear Seatback Lock Release |
| 72693 | Hook, Rear Seat Cushion Lock |
| 72995 | Cover, Rear Seat Cushion, RH |
| 72995E | Cover, Rear Seat Cushion |
| 72996 | Cover, Rear Seatback, RH |
| 72996A | Cover, Rear Seatback |
| 72997 | Cover, Rear Seatback, LH |
| 72998 | Cover, Rear Seat Cushion, LH |
| 73705 | Bracket Sub-assy, Child Restraint Seat Anchor, RH |
| 78920 | Cable Assy, Fold Seat Lock Control, NO.2 |
| 79977 | Felt, Seatback |
| 79977F | Felt, Seatback, LH |
| 79977K | Felt, Seatback, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
